Description
Product Description :
8-channel preamplifier :
With 16 additional digital inputs and outputs in ADAT format and AVB interface
Particularly suitable as an AVB extension to an existing Avid Pro Tools Carbon interface
Up to 2 Carbon Pre units can be used in combination with a Carbon base unit
Integrated control via Pro Tools software
Can also be used as a conventional preamplifier/converter combination with older Pro Tools HD systems and other interfaces
Resolution up to 32-bit/192kHz
8 combined inputs (XLR/Jack, balanced) with variable Z (inputs 5-8), dynamic range: 126 dB (A-weighted), THD+N: -105 dB (0.00056 %), frequency response: 20 Hz – 20 kHz , +/- 0.1 dB, ON: -129 dB (A-weighted)
8 line inputs (D-sub 25-pin, balanced), dynamic range: 125 dB (A-weighted), THD+N: -106 dB (0.0005 %), frequency response: 20 Hz – 20 kHz, +/- 0.1 dB
2 front-panel variable Z instrument inputs (6.3 mm jack, unbalanced), dynamic range: 125 dB (A-weighted), THD+N: -103 dB (0.0007%), frequency response: 20 Hz – 20 kHz, +/- 0.1 dB
8 line outputs (D-sub 25-pin, balanced), dynamic range: 120 dB (A-weighted), THD+N: -110 dB (0.0003%), frequency response: 20 Hz – 20 kHz, +/- 0.1 dB
WordClock input/output
Dimensions: 19” x 1U x 343 mm
Scope of delivery:
Pro Tools Carbon Pre
Power cord
Ethernet cable
Rack screws
Rubber feet
